A6006 Air Filter – Replacement for Sakura A-6006
Product Description
Our factory builds this model using 0.5 mm reinforced outer mesh, import-grade HV media, and ISO-tested dimensional control, making it a reliable replacement for the Sakura A-6006 filter.
This model is widely used in Caterpillar, Hitachi, Isuzu, Nissan, Clark, Daewoo, and John Deere equipment, and is especially popular among engine rebuilders and generator service companies.
Dimensions
| Parameter | Value |
|---|---|
| Outer Diameter (OD1) | 232 mm |
| Outer Diameter (OD2) | 232 mm |
| Inner Diameter (ID1) | 147 mm |
| Filter Height (H2) | 330 mm |
| Overall Height (H1) | 342.7 mm |
| Construction | Metal end caps + reinforced outer mesh |
| Media | High-efficiency HV cellulose media |
| Type | Primary air filter |
Applications
Caterpillar
320, 320L, 320N
330, 330L, 330N
350, 351, 352 series
3612, 3616 industrial engines
Multiple excavators & generator sets
Hitachi
EX200-2 / EX200-3 / EX200-5
EX300-2 / EX300-3 / EX300-5
ZX200, ZX230, ZX330 series
Isuzu
FORWARD series (FTR, FVR, FTR33, FTR90, etc.)
NPR/NQR trucks
6BG1, 6BD1, 6HK1 engines
Hino
METRUCK series
Various industrial diesel trucks
Nissan
Diesel forklifts and trucks from the FE / FD series
Clark
Multiple forklift models
Others
Komatsu, TCM, Daewoo industrial machines
Generator service companies using Isuzu/Hino engines
Replacement / Cross Reference
Isuzu: 1-14215817-0, 1-14215813-0, 1-14215821-0, 1-14215810-0, 1-14215828-0
Hino: 17801-1820, 17801-1821
Nissan: 16546-Z000, 16546-2101, 16546-21003
Toyota: 17801-2500
Caterpillar: 3I-0373, 42208E
Clark: Multiple forklift applications
John Deere: J20/20C and similar industrial models
Others: Hundreds of OEM references consolidated from the long sheet
Why Clients Choose Our Factory-Made A6006 Filter
Reinforced 0.5 mm outer mesh (stronger than 0.3 mm commonly used by low-cost factories)
HV high-efficiency media ensuring stable air flow and long service life
Tight dimensional tolerance for perfect sealing in OEM housings
Clean top & bottom metal caps produced by automated stamping
Used by generator service companies & fleet maintenance workshops
